LSR Injection Molding Machine

Huayi horizontal clamping machine, special design,national patent owner；

High safety, the clamping platens slides on the guider rails on the machine base；

Convenient operation, tiebar-less structure with upper space,convenient to load and install molds by crane or forklift；

Flexible to load the FRP Tube to inside the mold by crane and lifters；

Robust design of clamping unit and machine base with high stability and perfect parallelism；

Adopt close loop control injection, can cooperate with multi sets of molds with different phases pressure and speed setting；

LSR Clamping machine, pump machine, metering machine with molds can be offered as turnkey project.

Get A Free Quote

Get The Brochure

Product Description

LSR Injection Molding Machine

Item	HYZ-200F	HYZ-250F	HYZ-400F

Item	HYZ-200F	HYZ-250F	HYZ-400F
Clamping Force(KN)	2000	2500	4000
Heating Platen Size(W*L/MM)	800*1600	1250*2600	1500*3000
Space Btwn Platens(MM)	1600	2400	2700
Dimension Between Tiebar(MM)	With Out Tie Bar	With Out Tie Bar	With Out Tie Bar
Max.Clamping Stroke(MM)	1000	2000	2000
Min.Mold Thickness(MM)	610	410	710
Application	Liquid Silicone Rubber Hollow Core Bushing Solution
Machine Model	200F Clamping Machine With 200L Pump Machine	250F Clamping Machine With 200L Pump Machine	400F Clamping Machine With 200L Pump Machine
Insulators(KV)	110KV -220KV Hollow Core Insulators	400KV-500KV Hollow Core Insulators	750KV-1100KV Hollow Core Insulators

Features

LSR Injection Molding Machine

Huayi special design,state patent owner
High safety, the clamping platens slides on the guider rails on the machine base.
Convenient operation, tiebar-less structure with upper space,convenient to load and install molds by crane or forklift
Flexible to load the FRP Tube to inside the mold by crane and lifters
Robust design of clamping unit and machine base with high stability and perfect parallelism
Adopt close loop control injection, can cooperate with multi sets of molds with different phases pressure and speed setting
LSR Clamping machine, pump machine, metering machine with molds can be offered as turnkey project.
